尺寸: W(45)*H(32)*L(100)mm
产品特点>>>
1.交流输入电压：：AC175-265V 50/60HZ
2.保护种类：短路、过电流、过温度
3.内置恒电流限制电流
4.全防护铝型材外壳
5.ClassII电源
6.100%满载老化测试
7.高可靠性
8.主动式PFC功能
9.适用于LED照明
10.在-40℃~+70℃环境下稳定工作
11.防水等级IP65
12.效率：>90%
13.功率因数：>0.95
|
电源型号 Model |
功率 power |
输入电压 Input ltage |
输出电压/电流（5%） Output voltage/current |
外形尺寸 W*H*L(mm) |
|
XB-1218
|
AC175-265V
|
35-65V/300mA
|
12-18W
|
37*24*100mm
|
|
XB-2127
|
AC175-265V
|
50-90V/300mA
|
21-27W
|
45*32*100mm
|
|
XB-30-700
|
AC175-265V
|
25-30V/700mA
|
30W max
|
45*32*100mm
|
|
XB-50-700
|
AC175-265V
|
60-86V/700mA
|
50W max
|
45*32*100mm
|
|
JAX-80-700
|
AC175-265V
|
90-126V/700mA
|
80W max
|
50*32*134mm
|
|
JAX-120-700
|
AC175-265V
|
90-180V/700mA
|
120W max
|
50*35*170mm
|
|
JAX-180-700
|
AC175-265V
|
180-280V/700mA
|
150-180W max
|
64*34*190mm
|
|
XB-30-900
|
AC175-265V
|
22-36V/900mA
|
30W max
|
45*32*100mm
|
|
XB-50-1500
|
AC175-265V
|
22-36V/900mA
|
50W max
|
45*32*100mm
|
|
JAB-60-1800
|
AC175-265V
|
22-36V/900mA
|
60W max
|
46*32*125mm
|
|
JAX-80-2400
|
AC175-265V
|
22-36V/900mA
|
80W max
|
50*32*134mm
|
|
JAX-100-3000
|
AC175-265V
|
22-36V/900mA
|
100W max
|
50*35*134mm
|
|
具体输出电压、输出电流可按照客户要求定做 We can customize according to customer demands for power supply voltage or current |
||||
