尺寸: W(34)*H(23)*L(70)mm
产品特点>>
1.交流输入电压：：AC175-265V 50/60HZ
2.保护种类：短路、过电流、过温度
3.内置恒电流限制电流
4.ClassII电源
5.100%满载老化测试
6.高可靠性
7.主动式PFC功能
8.适用于LED照明
9.三年保修期
10.防护等级IP65
11.效率：>88%
12.功率因数：>0.9
|
电源型号 Model |
功率 power |
输出电压/电流（5%） Output voltage/current |
外形尺寸 W*H*L(mm) |
|
JAS-10-300
|
6-8W
|
18-30V/300mA
|
34*23*70
|
|
JAS-15-300
|
8-12W
|
22-42V/300mA
|
40*23*89
|
|
JAS-10-300/900
|
12W
|
22-35V/300mA 8-12V/900mA
|
40*23*89
|
|
JAS-15-400
|
15W
|
22-35V/400mA
|
40*23*89
|
|
JAS-20-300/480/600
|
20W
|
40-70V/300mA 28-42V/480mA 22-35V/600mA
|
43*25*111/43*38*65
|
|
JAS-30-300/450/600/900
|
30W
|
75-105V/300mA 50-70V/450mA 40-56V/600mA 22-35V/900mA
|
43*25*131/43*38*65
|
|
JAS-40-450/600/900/1200
|
40W
|
60V-84V/450mA 50-70V/600mA 30-42V/900mA 22-35V/1200mA
|
63*30*80
|
|
JAS-50-600/900/1200/1500
|
50W
|
60-84V/600mA 40-56V/900mA 30-42V/1200mA 22-35V/1500mA
|
63*30*80
|
|
具体输出电压、输出电流可按照客户要求定做 We can customize according to customer demands for power supply voltage or current |
|||
